Description
The Agilent 8453 G1103A Single Cell Spectrophotometer is a reliable UV‑Visible spectrophotometric system designed for rapid and accurate absorbance measurements in analytical and research laboratory environments. Utilizing diode‑array detection technology, the 8453 provides fast spectral acquisition and stable performance across the UV‑Vis wavelength range. This single‑cell configuration is well suited for routine quantitative analysis, method development, and quality control applications. The system’s design supports consistent optical performance and ease of operation, making it a practical solution for laboratories requiring dependable UV‑Vis measurements with minimal complexity.The Agilent 8453 spectrophotometer is commonly used in pharmaceutical analysis, chemical research, life‑science laboratories, and educational settings, where reproducibility and straightforward operation are essential.
Agilent 8453 G1103A Single Cell Spectrophotometer is offered fully refurbished and tested, in working condition.
System Includes:
- Agilent 8453 UV‑Visible Diode Array Spectrophotometer
- Single Cell
- Dell PC with Windows 11 Pro and Data System
- 30-Day Warranty
Optional:
- Premium refurbishment available with extended warranty options
Disclaimer: All brand names and trademarks are the property of their respective owners and are used for identification only. We are not an authorized dealer. Software, if included, is not transferable or upgradable.
Agilent 8453 UV‑Visible Spectrophotometer Specifications
Optical Specifications
- Wavelength Range: 190 – 1100 nm
- Optical Design: Diode array (1024‑element PDA)
- Slit Width: 1 nm
- Resolution (EP Test): > 1.6 (0.02% v/v toluene in hexane, 269/266 nm)
Wavelength Performance
- Wavelength Accuracy:
- < ±0.5 nm (NIST 2034)
- < ±0.2 nm at 486.0 and 656.1 nm
- Wavelength Reproducibility: < ±0.02 nm (10 consecutive scans)
Photometric Performance
- Photometric Accuracy:
- < ±0.005 AU at 1 AU (NIST 930e)
- < ±0.01 AU (EP potassium dichromate method)
- Photometric Noise: < 0.0002 AU RMS (60 scans, 0.5 s, 500 nm)
- Photometric Stability: < 0.001 AU/hour (after 1‑hour warm‑up)
- Baseline Flatness: < 0.001 AU RMS
Stray Light
- < 0.03% at 340 nm (NaNO₂, ASTM)
- < 0.05% at 220 nm (NaI, ASTM)
- < 1% at 200 nm (KCl, EP)
Speed & Throughput
- Typical Full‑Range Scan Time: 1.5 seconds
- Shortest Scan Time: 0.1 seconds
Light Sources
- Deuterium Lamp (UV)
- Tungsten Lamp (Visible)
Pre‑aligned for easy replacement
Sample Handling
- Cells Supported: 1 cuvette
- Pathlength: Typically 10 mm (other pathlength cuvettes supported)
- Cell Types: Quartz (UV/Vis), glass (Vis only)
- Operation: Manual insertion and measurement
Physical & Environmental
- Dimensions (H × W × D): 185 × 344 × 560 mm
- Weight: ~16.5 kg (36.3 lb)
- Operating Temperature: 0 – 50 °C
- Power Requirements: 90–264 VAC, 47–63 Hz
Connectivity & Software
- Interfaces: LAN, GPIB, GPIO for accessories
- Software: Agilent UV‑Vis ChemStation (GLP, EP/USP compliant; 21 CFR Part 11 optional)
