Description
The Agilent 1200 Series G1315B Diode Array Detector (DAD) is a versatile UV‑Vis detector designed for simultaneous multi‑wavelength detection in high‑performance liquid chromatography (HPLC) applications. Utilizing diode‑array technology, the G1315B captures full spectral information across the ultraviolet and visible range, supporting reliable quantitative analysis, compound identification, and peak purity assessment. Designed for seamless integration with Agilent 1200 Series HPLC systems, the G1315B DAD delivers stable baseline performance and reproducible detection for a wide range of analytical workflows. Its broad wavelength coverage and spectral acquisition capability make it well suited for both routine analysis and more advanced method development.
Agilent 1200 Series G1315B Diode Array Detector (DAD) is offered fully refurbished and tested, in working condition.
Includes:
- Agilent 1200 Series G1315B Diode Array Detector (DAD)
- Power Cable
- 30-Day Warranty
Optional:
- Premium refurbishment available with extended warranty options
Disclaimer: All brand names and trademarks are the property of their respective owners and are used for identification only. We are not an authorized dealer. Software, if included, is not transferable or upgradable.
Technical Specifications
Agilent 1200 Series G1315B Diode Array Detector (DAD)
Detector Type
- Detection Method: UV‑Visible Diode Array Detection (DAD)
- Optical Design: Deuterium lamp with diode‑array spectrometer
Wavelength Performance
- Wavelength Range: Approximately 190–950 nm
- Wavelength Accuracy: ±1 nm
- Wavelength Precision: ±0.1 nm
- Spectral Bandwidth: ~2 nm
Performance Characteristics
- Noise: Very low baseline noise (µAU level, method‑dependent)
- Drift: Minimal long‑term drift for stable quantitation
- Data Output: Simultaneous multi‑wavelength and full spectral data
- Peak Purity Analysis: Supported
Flow Cell
- Standard Flow Cell: Analytical UV flow cell
- Path Length: Typically 10 mm (variant‑dependent)
Software & Integration
- Control Software:
- Agilent ChemStation
- Agilent OpenLab CDS
- System Compatibility:
- Agilent 1100 Series HPLC
- Agilent 1200 Series HPLC
Electrical & Physical
- Module Type: Stackable HPLC detector
- Communication: Agilent CAN‑based LC system control
- Intended Environment: Analytical laboratory use
Typical Applications
- Pharmaceutical quality control (QC)
- Method development and validation
- Chemical and environmental analysis
- Food and beverage testing
- Academic and industrial chromatography labs
