Description
The Agilent 6550 iFunnel Quadrupole Time‑of‑Flight (Q‑TOF) LC/MS System is a high‑resolution mass spectrometry platform designed for accurate mass measurement, high sensitivity, and advanced qualitative analysis. Featuring Agilent’s iFunnel ion focusing technology, the 6550 Q‑TOF delivers enhanced ion transmission and sensitivity, making it well suited for complex sample analysis and trace‑level detection. Designed for seamless integration with compatible Agilent LC systems, the 6550 iFunnel Q‑TOF enables reliable high‑resolution LC‑MS workflows for compound identification, structural elucidation, metabolomics, proteomics, small‑molecule analysis, and impurity profiling. Its fast acquisition speed and accurate mass capability support confident characterization of unknown compounds and complex mixtures. The Agilent 6550 iFunnel Q‑TOF LC/MS system is widely used in pharmaceutical research, biotechnology, environmental analysis, food safety testing, and academic research laboratories, where high mass accuracy and reproducible performance are essential.
This Agilent 6550 iFunnel Q‑TOF LC/MS System is offered fully refurbished and tested, in working condition.
Includes:
- Agilent 6550 iFunnel Q‑TOF LC/MS system
- Jet Stream Electrospray Ionization (ESI) Source
- Integrated Time‑of‑Flight (Q‑TOF) Analyzer
- Two (2) Vacuum Pumps
- Dell PC with Windows 11 Pro and Data System
- 30- Day Warranty
Optional:
- Agilent UHPLC Front End Systems (1260 or 1290 Infinity Series)
- APCI or Multimode Ion Source
Disclaimer: All brand names and trademarks are the property of their respective owners and are used for identification only. We are not an authorized dealer. Software, if included, is not transferable or upgradable.
Mass Spectrometer
Agilent 6550 iFunnel Q-TOF LC/MS
- Analyzer Type: Quadrupole Time‑of‑Flight (Q‑TOF)
- Technology: Agilent iFunnel Ion Source with Jet Stream ESI
- Mass Range:
- MS: m/z 100–10,000
- Extended Range: m/z 50–1,700 or up to 3,200 (mode‑dependent)
- Quadrupole Mass Range: Up to m/z 4,000
Resolution & Mass Accuracy
- Resolving Power:
- 25,000 FWHM at m/z 322
- 42,000 FWHM at m/z 2,722
- Mass Accuracy (MS):
- <1 ppm RMS with internal mass correction
- Mass Accuracy (MS/MS):
- <2 ppm RMS
- Mass Stability: <1 ppm over wide temperature ranges
Sensitivity & Dynamic Range
- MS Sensitivity:
- 1 pg reserpine, S/N ~1,000:1
- MS/MS Sensitivity:
- 1 pg reserpine, S/N up to ~4,500:1 (maximum sensitivity mode)
- Dynamic Range: Up to 5 orders of magnitude (in‑spectrum)
Speed & Acquisition
- Acquisition Rate:
- Up to 50 spectra/second (MS and MS/MS)
- Polarity Switching: ~1.5 seconds full cycle
- Scan Modes:
- MS
- MS/MS (DDA and targeted)
- All Ions MS/MS
- Targeted accurate‑mass analysis
Ionization & Interfaces
- Standard Source: Agilent Jet Stream ESI with iFunnel
- Optional Sources: APCI, Multimode (ESI/APCI), GC‑APCI
- LC Compatibility: Agilent 1260 & 1290 Infinity Series, UHPLC
Vacuum & Electronics
- Flight Tube: INVAR‑stabilized TOF for thermal stability
- Digitizer: 4 GHz high‑speed digitizer
- Vacuum System: High‑efficiency turbo molecular pumping optimized for Q‑TOF performance
Software
- Control & Analysis: Agilent MassHunter Workstation
- Capabilities:
- Accurate‑mass MS & MS/MS
- Molecular formula generation
- Compound profiling and identification
- Quantitative and qualitative workflows
Typical Applications
- Metabolomics & metabolite identification
- Proteomics and targeted proteomics
- Biopharmaceutical & pharmaceutical analysis
- Food safety testing
- Forensics & toxicology screening
- Environmental analysis
