Agilent 1260 Infinity HPLC Front End System with Binary Pump, Autosampler & TCC

1. Agilent 1260 Infinity G4225A HiP Degasser – Specifications

Performance

• Number of solvent channels: 4
• Flow range: 0 – 10 mL/min per channel
• Internal volume: 0.45 mL per channel
• pH range: 1 – 14
• Materials: TFE/PDD copolymer, FEP, PEEK

 Physical

• Dimensions: 80 × 345 × 435 mm
• Weight: ~5 kg (11 lb)

1. Agilent 1260 Infinity G1312B Binary Pump – Specifications

 Performance

• Flow range: 0.05 – 5.0 mL/min
• Settable range: 0.001 – 5.0 mL/min
• Pressure range: 0 – 600 bar (up to ~8700 psi)
• Flow precision: ≤ 0.07% RSD
• Flow accuracy: ±1% or 10 µL/min
• Gradient type: High-pressure binary mixing
• Composition range: 0 – 100% [
• Recommended pH: 1.0 – 12.5

 Physical

• Dimensions: 180 × 345 × 435 mm
• Weight: 15.5 kg (34 lb)

1. Agilent 1260 Infinity G1329B Autosampler – Specifications

 Performance

• Injection range: 0.1 – 100 µL
• Max volume (multi-draw): Up to 1500 µL
• Injection precision: < 0.25% RSD
• Carryover: < 0.1% (down to 0.05%)
• Pressure range: 0 – 600 bar
• Sample capacity:
  • 100 × 2 mL vials
  • 40 × 2 mL (half tray)
• Cycle time: ~50 seconds per injection

Physical

• Dimensions: 200 × 345 × 435 mm
• Weight: 14.2 kg (32 lb)

1. Agilent 1260/1200 Series G1316A TCC – Specifications

 Performance

• Temperature range: ~10°C below ambient to 80°C
• Temperature stability: ±0.15°C
• Temperature accuracy: ±0.8°C (±0.5°C calibrated)
• Column capacity: Up to 3 × 30 cm columns
• Internal volume: ~9 µL (low dispersion)

 Physical

• Dimensions: 410 × 435 × 140 mm
• Weight: 10.2 kg (22.5 lb)
